Yamaha YZF R15 v3 2019-2020

Dimensions:
Overall Length: 1990 mm. (78.3 in.)
Overall Width: 725 mm. (28.5 in.)
Overall Height: 1135 mm. (44.7 in.)
Seat Height: 815 mm. (32.1 in.)
Wheelbase: 1325 mm. (52.2 in.)
Ground Clearance: 170 mm. (6.69 in.)
Minimum Turning Radius: 2.8 m. (9.19 ft.)

Weight:
Curb Weight: 137 kg. (302 lb.)
Engine:
Combustion Cycle: 4 Stroke
Cooling System: Liquid cooled
Valve Train: SOHC
Number of Cylinders: Single Cylinder
Displacement: 155.1 cm3
Bore X Stroke: 58.0 X 58.7 mm. (2.28 X 2.31 in.)
Compression Ratio: 11.6:1
Engine:
Starting System: Electric starter
Lubrication System: Wet sump

Engine Oil:
Recommended Brand: Yamalube
SAE Viscosity Grades: 10W-40 or 20W-40
Recommended Engine Oil Grade: API service SG type or higher,
JASO standard MA
Engine Oil Quantity:
Oil Change: 0.85 L (0.90 US qt., 0.75 lmp. qt.)
With Oil Filter Removal: 0.95 L (1.00 US qt., 0.84 lmp qt.)
Coolant Quantity:
Coolant Reservoir (up to the maximum level mark):
0.15 L (0.16 US qt., 0.13 lmp. qt.)
Radiator (including all routes):
0.49 L (0.52 US qt., 0.43 lmp. qt.)
Air Filter:
Air Filter Element:
Dry Element
Fuel:
Recommended Fuel:
Regular unleaded gasoline only
Fuel Tank Capacity:
11 L (2.9 US gal., 2.4 lmp. gal.)
Fuel Reserve Amount:
1.9 L (0.50 US gal.,0.42 lmp. gal.)
Fuel Injection:
Throttle body:
ID mark: BK61 00
Spark Plug(s):
Manufacturer/model: NGK/MR8E9
Spark plug gap: 0.8-0.9 mm. (0.031-0.035 in.)
Clutch:
Clutch type: Wet, multiple-disc
Drivetrain:
Primary reduction ratio:
3.042 (73/24)
Final drive:
Chain
Secondary reduction ratio:
3.429 (48/14)
Transmission type:
Constant mesh 6-speed
Drivetrain:
Gear ratio:
1st: 2.833 (34/12)
2nd: 1.875 (30/16)
3rd: 1.364 (30/22)
4th: 1.143 (24/21)
5th: 0.957 (22/23)
6th: 0.840 (21/25)
Chassis:
Frame type:
Diamond Caster Angle: 25.5°
Trail: 88 mm. (3.5 in.)
Front Tire:
Type: Tubeless
Size: 100/80-17M/C 52P
Manufacturer/model: IRC/RX-01F

Rear Tire:
Type: Tubeless
Size: 140/70-17M/C 66S
Manufacturer/model: IRC/RX-01R
Loading:
Maximum load:
168Kg (370 lb.)
(Total weight of rider, passenger, cargo and accessories)
Tire Air Pressure (measured on cold tires):
1 person:
Front: 225 kPa (2.25 kgf/cm2, 33 psi.)
Rear: 250 kPa (2.50 kgf/cm2, 36 psi.)
2 Persons:
Front: 225 kPa (2.25 kgf/cm2, 33 psi.)
Rear: 250 kPa (2.50 kgf/cm2, 36 psi.)
Front Wheel:
Wheel type: Cast wheel
Rim size: 17M/C X MT2.5
Rear Wheel:
Wheel type: Cast wheel
Rim size: 17M/C X MT4.0
Front Break:
Type: Hydraulic single disc break
Specified brake fluid: DOT 3 or 4
Rear Brake:
Type: Hydraulic single disc break
Specified brake fluid: DOT 3 or 4

Front Suspension:
Type: Telescopic fork
Spring: Coil spring
Shock absorber: Hydraulic damper
Wheel travel: 130 mm. (5.1 in.)
Rear Suspension:
Type: Swingarm (link suspension)
Spring: Coil spring
Shock absorber: Hydraulic damper
Wheel travel: 97 mm. (3.8 in.)
Electrical System:
System voltage: 12V
Ignition System: TCI
Charging System: AC Magneto
Battery:
Model:GTZ4V
Voltage capacity: 12V, 3.0 Ah (10HR)
Bulb Wattage:
Headlight: LED
Brake/tail light: LED
Front turn signal light: 10.0 W
Rear turn signal light: 10.0 W
Auxiliary light: LED
License plate light: 5.0 W
Meter lighting: LED

Bulb Wattage:
Neutral indicator light: LED
High beam indicator light: LED
Turn signal indicator light: LED
Coolant temperature warning light: LED
Engine trouble warning light: LED
Shift timing indicator light: LED
Fuse(s):
Main fuse: 15.0 A
Accessory fuse: 2.0 A
